Planetary Mixers for Concrete
In the field of paving block production, achieving a homogeneous concrete mix is crucial. The SPM family of planetary mixers is the key to unlocking precision and efficiency.
Application of SPM planetary mixers
Planetary mixer SPM / SPMW is a machine designed for professional and precise preparation of various types of dry and wet mixtures.
| ✅ | Semi-dry concrete | ✅ | Building mortar | ✅ | Dry mortar |
| ✅ | Dry concrete | ✅ | Granules | ✅ | Dry plaster |
| ✅ | Colored concrete | ✅ | Ceramic mass | ✅ | Chamotte |
| ✅ | Concrete for the facade | ✅ | Floor screed mass | ✅ | Fertilizers |
| ✅ | Ready-mixed concrete | ✅ | Abrasive materials | ✅ | Loose feed |
| ✅ | Concrete for bricks | ✅ | Rock flour | ✅ | Chemicals |
| ✅ | Light concrete (pumice) | ✅ | Glass mix |
Configurable discharges
|
|
|
|
Concrete mixing cycle (IAB Laboratory)
The mixing process was tested at an IAB accredited laboratory in Germany. The use of a high-speed mixer reduced mixing time by 20%. The mix is homogeneous, ideal for the preparation of top layer concrete, facemix, colormix, etc. The high homogeneity of the concrete mixture reduces waste by more than 90%.
SPM-500 planetary mixer
Total mixing time 5 minutes

Planetary mixer SPMW-500 (with high-speed agitator)
Total mixing time 4 minutes

Dimensions of SPM planetary mixers
SPM-500

SPM-750

SPM-1125

SPM-1750

SPM-2250

SPM-3000

SPM-3750

- Quick mixing cycle
- Precise mixing of concrete thanks to the optimal number of mixing feet
- Compact construction
- Simple operation and easy maintenance
- Moisture probe as standard
- Ready to work with any production line
- Safety – door lock during operation
- Quiet operation
- High-speed agitator (optional) – best effect for top layer concrete
- Up to 90% less waste by using a high-speed agitator
- Cement savings
- Saving hours of work
Feed capacity (l/kg)
Unit capacity per cycle (m3)
Minimum feed capacity (l/kg)
Minimum capacity per cycle (m3)
Example mixing time (s)
Weight of mixer (kg)
Gearmotors power (kW)
Number of discharge chute as standard (pc.)
SPM-500
SPM-750
SPM-1125
SPM-1750
SPM-2250
SPM-3000
SPM-3750
500/820
750/1200
1125/1800
1750/1200
2250/3600
3000/4800
3750/6000
0,33
0,5
0,75
0,75
1,5
2
2,5
130/200
188/300
281/450
455/700
564/900
780/1200
975/1500
0,1
0,5
0,75
0,4
0,4
0,6
0,8
108
108
120
137
137
137
170
2850/3350
4200/4850
4800/5120
8600
8800
10000
13900
15 + 11
2 x 9,2 + 15
2 x 15 + 15
2 x 22
2×30
2×37
2×55
1 (bottom)
1 (bottom)
1 (bottom)
1 (bottom)
1 (bottom)
1 (bottom)
1 (bottom)
